Model NO.	FPC-T030
Combination Mode	Adhesive Flexible Plate
Application	Digital Products, Computer with LCD Screen, Mobile Phone, Aviation and Aerospace
Conductive Adhesive	Conductive Silver Paste
Flame Retardant Properties	V0
Processing Technology	Delay Pressure Foil
Base Material	Pi/Pet
Insulation Materials	Organic Resin
Brand	Smart
Supplier Type	Manufacturer
Copper Thickness	0.5oz-3oz
Min. Hole Size	0.15mm
Min.Line Width	0.075mm
Min.Line Spacing	0.075mm
Board Thickness	0.057-0.6mm
Stiffener	Without, Top, Bot, Both Sides
Surface Finishing	Enig, Immersion Silver, OSP
Solder Mask(Coverlay)	Yellow, White, Black
Transport Package	Carton
Specification	Customized
Trademark	Smart
Origin	Guangdong, China
HS Code	8534009000
Production Capacity	500000/Year

Packaging & Delivery

Package Size20.00cm * 15.00cm * 10.00cm Package Gross Weight1.000kg

Product Description

Serial Number	Item	Process Capability	Tolerance
01	Number of layers	1-16	MAX:500X3000MM
02	Production plate size	MAX:250X3000MM	0.08MM
03	Drilled Hole Diameter	MIN:250X1500MM	0.03MM
04	Tolerance of drilled hole diameter	6.5MM/0.1MM	15-40UM
05	Copper thickness in hole	±0.05MM	0.05MM/0.05MM
06	Etched line width/spacing	8-12UM	/
07	Etch Tolerance	0.07MM/0.07MM	/
08	Pattern-to-Pattern Accuracy	± 20%(MIN ± 0.03MM)	±0.076MM
09	Overlay Film Alignment Tolerance	±0.076MM	/
10	Punch Hole Diameter	±0.15MM	/
11	Soldermask Alignment Tolerance	3.175MM/2.0MM	/
12	Green Oil Bridge	±0.2MM	/
13	Green Oil to PAD	0.1MM	/
14	Character to PAD	0.08MM	0.15MM
15	Most Power Point Test Pad	0.2MM	/
16	Form Factor Tolerance Range	0.2MMX0.2MM	±0.05MM
17	Finger Edge Spacing	Stroke 0.1MM 0.1MM	0.05MM

Type		Product Type	Production Cycle
Lead Time	Sample	Single Sided FPC	5-6 days
		Double-sided FPC	6-7 days
		Multi-layer FPC	8-9 days
		Rigid-flex FPC	10-12 days
		Expedited	24-48 hours
	Batch	Single Sided FPC	7-8 days
		Double-sided FPC	9-10 days
		Multi-layer FPC	10-12 days
		Rigid-flex FPC	10-14 days
		Small batch expedited	3-5 days
